Belarus 250As Tractor Parts: Where To Find Them

Belarus 250AS tractor parts are available from various online retailers, including eBay and All States Ag Parts. Parts for sale include fuel filters, fuel filter O-rings, compression washers, fuel filter screens, ground switches, power steering bearings, rear axle/PTO seals, and bushings. Some parts come with a free 1-year warranty.

Fuel filters

When it comes to the Belarus 250AS tractor, there are a few different options for fuel filters available in the market. One option is the fuel filter specifically designed for the Belarus 250AS tractor, which is compatible with older models of the tractor, including the T25 and Nortrac 250a. These fuel filters are highly regarded by users, with an average rating of 4.38 out of 5 stars. They are known to get the job done and help get vintage tractors running again.

Another option for the Belarus 250AS tractor is the new type of fuel filter, which comes in a set of two. These filters are designed to fit the Belarus 250AS, as well as other models in the series, such as the T25, T30, T40, 300, 400, and 1500.

It is worth noting that fuel filters are not a one-size-fits-all component, and it is crucial to ensure that you purchase the correct fuel filter for your tractor model. Using the wrong fuel filter can lead to improper fitment and potential damage to the fuel system. Therefore, it is always recommended to consult a professional or refer to the tractor's manual before making any purchases.

In addition to the fuel filters themselves, there are also a few related parts worth considering. For instance, the fuel filter screen for the Belarus 250AS tractor helps to catch larger contaminants before they reach the fuel filter, extending the filter's lifespan. Similarly, the fuel tank cap plays a vital role in preventing dust and debris from entering the fuel tank, which could otherwise clog the fuel filter prematurely.

Hydraulic parts

The Belarus 250AS tractor has many hydraulic parts available for purchase, including:

• Hydraulic valve and lift cylinder seal kits
• Hydraulic pump seal kits
• Hydraulic pump (4-spline drive)
• Hydraulic filter kits

In addition, there are many other parts available for the Belarus 250AS tractor, such as:

• Fuel filters
• Fuel tank filter screens
• Fuel tank caps
• Fuel hand pumps
• Fuel hoses
• Fuel pump plastic covers
• Fuel pump gaskets and seals
• Fuel washers
• Fuel transfer pump rebuild kits
• Fuel pipes
• Fuel level sensors
• Engine oil filters
• Engine oil caps
• Engine glow plugs
• Fan belts
• Steering box bearings and oil seals
• Starter motors
• Gearbox lever covers
• Gearbox shift boots
• Gearbox covers
• Tie rod end seals
• Brake bands
• Clutch bearings
• Fuse boxes
• Temperature gauges
• Flashlights
• Switches
• Tachometer cables
• Injection pump cover plates
• Throttle controls
• Wiring diagrams

Electrical parts

The Belarus 250AS tractor has a reputation for a subpar electrical system. Owners have reported various issues with the tractor's electrical components, including the alternator, ammeter, and fuel gauge.

Alternator

The alternator on the Belarus 250AS has been known to cause issues. One owner reported that their alternator magnetized a saw blade. A simple way to test the alternator is to check the battery voltage when the tractor is not running and then again when it is running. The battery voltage should be in the 12.5-volt range when the tractor is not running and in the 13-14 volt range when it is running.

Ammeter

The ammeter on the Belarus 250AS has also been a source of frustration for owners. It is important to note that issues with the ammeter may be related to problems with the alternator, as they are part of the same electrical system.

Fuel Gauge

The fuel gauge on the Belarus 250AS has been reported to malfunction, possibly due to a faulty sending unit. The sending unit is a simple rheostat, and the resistance should increase or decrease when an ohmmeter is connected and the sending unit is moved.

Fuse Panel

The Belarus 250AS utilizes a unique fuse panel that uses replaceable wire fuses instead of the more common blade fuses. These wire fuses are rated at 10 amps and 20 amps. While it is possible to convert the fuse panel to accept blade fuses, it is important to ensure that the amps remain the same.

Other Electrical Issues

In addition to the specific issues mentioned above, owners have reported a range of other electrical problems with the Belarus 250AS. These include difficulties with the ignition switch, starter, and injector pump. Given the number and variety of electrical issues reported, it is clear that the electrical system of the Belarus 250AS tractor requires careful maintenance and attention.

Engines and engine parts

The Belarus 250AS tractor is equipped with a 2.1L 2-cylinder diesel engine. The engine is air-cooled and has a piston displacement of 127 cubic inches (2.08 litres). The bore is 4.134 inches (105mm) and the stroke is 4.724 inches (120mm). The engine's lubrication system uses a gerotor oil pump and a centrifugal oil filter, which was replaced by a canister filter in later models. The fuel system includes a rotary plunger fuel injection pump and one primary and two secondary oil bath fuel filters. The engine cooling system is air-cooled with a belt-driven fan.

For the engine, you can find the following parts:

• Fuel filters
• Fuel tank cap
• Fuel tank filter screen
• Fuel hoses
• Fuel pump plastic cover
• Fuel hand pump
• Fuel pump gaskets and seals kit
• Fuel pump
• Fuel pipe
• Fuel transfer pump rebuild kit
• Fuel washers
• Fuel level sensor
• Glow plug
• Engine gasket kit
• Engine oil filter
• Engine oil cap

In addition to the above, there are several other parts available for the Belarus 250AS tractor, including those for the clutch, brakes, hydraulics, steering, electrical system, and transmission.

Manuals and books

There are a number of manuals and books available for the Belarus 250AS tractor. These include:

Belarus 250AS Tractor Operators Manual

This manual is available as a printed copy or a PDF digital download from Jensales. It contains critical everyday use and preventative maintenance information for the tractor, including lubrication, capacities, minor adjustment procedures, and other important usage information. It is available in English and French.

Belarus 250AS Tractor Operators Owners Operations Manual

This manual is available from Peaceful Creek Supply via Amazon. It is a new print of an original equipment manufacturer (OEM) manual. It has full-size heavy covers and is well-bound for durable use. It is also available in English.

Belarus 250AS Tractor Operators Manual

This manual is available from Misc. Tractors Manuals via Amazon. It is a high-quality reproduction of factory manuals from the OEM. It supplies detailed information on the controls, gauges, adjustments, operating instructions, maintenance procedures, and troubleshooting tips for the tractor. It is available in paperback format and in English.

Belarus 250AS Tractor Operator's Manual Book Catalog OEM

This pre-owned operator's manual is available from eBay.
